New Design 2026
- Luxury Series
- · Double Storey
The Tarneit
52
A grand double-storey residence crafted for modern family life — featuring a prayer room, study retreat, butler’s pantry, kitchenette, and a sophisticated facade combining Moonshadow brickwork with vertical Classic Cedar cladding.
4
BADROOMS
3+
BATHROOMS
475
M² TOTAL
7
ENERGY
Floor Plan Overview
Two Levels of Thoughtful Living
Ground Floor
- Formal Living Room
- Family & Meals Area
- Kitchen with Butler's Pantry (WIP)
- Guest Room with WIR & Ensuite
- Powder Room (PDR)
- Laundry
- Double Garage — 43.60 m²
- Covered Porch — 5.28 m²
- 2× Storage Rooms
First Floor
- Master Bedroom 1 with WIR & Ensuite
- Bedroom 2 with WIR & Ensuite
- Bedroom 3 with WIR
- Bedroom 4 with WIR
- Prayer Room
- Study / Desk Area
- Retreat Space
- Kitchenette
- Balcony — 11.33 m²
- Void over Ground Floor
Technical Specifications
Built to the Finest Standards
Site & Structure
Site Area
464 m² (Lot 1636)
Total Floor Area
475.35 m² (51.2 SQ)
Building Coverage
58.0%
Soil Classification
Class H2 — AS2870-2011
Roof Type
Colorbond Flat — 2° Pitch
Staircase
17 Risers, Internal Posi-Strut
Flooring System
Waffle Pod — 385mm overall
Slab Type
Posi-Strut — First Floor
Compliance & Ratings
Bushfire Attack Level
BAL 12.5 — AS3959-2018
Energy Star Rating
7.0 Star NatHERS
Termite Zone
TBB — AS3660.1 compliant
Building Permit
CBS-U 66127/9877343742828
Livable Housing
LHDS Part 5 — Hobless Shower
Designed By
Project D — Huu Nam Tran Dang
Designer Registration
DP-AD 65315
Issued Date
26 May 2026
Ready to Build Your
Dream Home?
The Tarneit 52 is available for construction on your chosen lot. Our team will guide you through every step — from design customisation to handover keys.
Starting From
POA
Price on Application · Site costs included in estimate
